# GUI Auth
#### Signing In: Username and Password
When you open the Evento GUI, you are greeted by a branded login page. Authentication uses a standard **username and password** over **HTTP Basic auth** — there are no tokens to generate, no application logs to scrape, and no token expiry.
The Evento GUI login page
The credentials are the ones configured on the Evento Server through Spring Boot's in-memory user:
* `spring.security.user.name` — the login username (default: `evento`)
* `spring.security.user.password` — the login password (default: `secret`)
{% hint style="warning" %}
The defaults (`evento` / `secret`) are for local exploration only. **Always override both properties in any real deployment**, e.g. by setting the `SPRING_SECURITY_USER_NAME` and `SPRING_SECURITY_USER_PASSWORD` environment variables on the server container.
{% endhint %}
#### How It Works
* The login page verifies your credentials directly against the server; on success you land on the dashboard.
* The GUI attaches the credentials as an `Authorization: Basic` header to every API call, and caches them in the browser's localStorage so the session survives page reloads.
* If the server ever rejects your credentials (401) — for example after the password is changed — the GUI clears the stored credentials and redirects you back to the login page.
* If you are signed in but lack the role an action needs (403), the GUI tells you so ("This action needs the ADMIN role.") and keeps you signed in.
* Use the **logout** button in the header to clear the stored credentials at any time.
#### Single Sign-On with OpenID Connect
Since Evento **3.0** the console can sign users in through your organisation's identity provider (Keycloak, Entra ID, Okta, Google Workspace, …) instead of the shared user:
```properties
evento.server.web.auth=oidc # EVENTO_SERVER_WEB_AUTH
spring.security.oauth2.client.registration.evento.client-id=evento-console
spring.security.oauth2.client.registration.evento.client-secret=${OIDC_CLIENT_SECRET}
spring.security.oauth2.client.registration.evento.scope=openid,profile,email
spring.security.oauth2.client.provider.evento.issuer-uri=https://login.example.com/realms/acme
# which groups grant the console's roles
evento.server.web.oidc.roles-claim=groups # e.g. roles (Entra ID), realm_access.roles (Keycloak)
evento.server.web.oidc.web-role=evento-web # read the console
evento.server.web.oidc.admin-role=evento-admin # also consumer operations
```
Register the console at the provider as a confidential web client with the redirect URI `https:///login/oauth2/code/evento`.
* The login page shows **Sign in with your organisation**: the server runs the authorization-code flow (with PKCE) and brings you back to the dashboard.
* The session lives in an HttpOnly cookie; no token reaches the browser. Changes (consumer operations) carry a CSRF token the GUI reads from the `XSRF-TOKEN` cookie.
* A user whose groups grant neither role can sign in but sees nothing (every API call answers 403).
* HTTP Basic stays available for machine clients, e.g. a Prometheus scrape of `/actuator/prometheus` with the configured user.
#### Roles
* `WEB` reads the console: dashboard, catalog, flows, cluster status, consumers, event store.
* `ADMIN` is needed for every change: retrying, deleting or replaying dead events, and removing a bundle from the catalog (`DELETE /api/bundle/{id}`).
The Basic user gets both roles; with OIDC they come from the provider's groups.
#### Audit Trail
Since Evento **3.0** the server records who did what in the console (on by default; `management.auditevents.enabled=false` turns it off):
| Event | When |
| ---------------------------------- | -------------------------------------------------------------------------------------------------------------------------------------------------------- |
| `ADMIN_ACTION` | every change, with the action, its target, the caller's address and the outcome (`ok`, or `failed` with the error), written when the bundle has answered |
| `AUTHENTICATION_FAILURE` | a wrong password, a failed OIDC sign-in |
| `AUTHENTICATION_SUCCESS`, `LOGOUT` | OIDC sign-in and sign-out (Basic re-authenticates on every request, so its successes are not recorded) |
| `AUTHORIZATION_FAILURE` | a signed-in user refused an action its roles do not grant |
Each event is one line on the `evento.audit` logger:
```
event=audit type=ADMIN_ACTION principal=alice action=consumer.dead_queue.consume consumerId=orders_OrderProjector_1_default remoteAddress=10.0.4.17 outcome=ok
```
That log is the durable record: route the `evento.audit` logger to your SIEM or to an append-only file. The latest events (`evento.server.audit.capacity`, default 1000) are also at `/actuator/auditevents`, for `ADMIN` users only; they are kept in memory and lost on restart. `management.auditevents.enabled=false` turns the audit off.
#### Scope of Authentication
All GUI pages and every `/api/**` endpoint require authentication; only the health/info actuator probes are public. Note that this login protects the **web GUI and REST API**. Bundle connections on the message bus are authenticated separately with the optional wire-level shared secret (`evento.server.bus.auth-token`, see [Advanced Options](/evento-server/setup-evento-server/advanced-options.md)).
